"Easy and Fast" small volume sample preparation column
MonoSpin Series
The first choice SPE columns for quick sample preparation
MonoSpin is a SPE (Solid Phase Extraction) column with monolithic silica (monolith). This is designed for
small volume sample preparation by centrifuge. GL Sciences' unique monolith silica technology.
GL Sciences’ monolith silica technology has low-pressure, high-flow, and low-liquid-retention properties,
makes it uniquely suited for handling small amount samples.
Features
- Easy to Operate
Easy operation by centrifuge, also multiple samples are processed simultaneously. With little or no liquid retained by the separation material, elution is processed efficiently.
- Fast
Excellent mass transfer and rapid sample binding on MonoSpin’s monolith silica allows extremely rapid sample preparation compared with other methods.
- Ideal for Small Sample Volume
Excellent for the pretreatment for samples of 50 – 800 μL
- Wide Variety of Functional Groups
10 kinds of functional groups (C18, -NH2, Amide, TiO, etc...) are available for MonoSpin series, allowing almost any type of compounds to be purified.
・ Two sizes
- S type (Short type)
Disc size : Φ 4.2 x 1.5 mm
Sample volume : up to 800 μL
Elution volume : 50 – 800 μL
Centrifuge : 2000 - 10000 x g
- L type (Long type)
Disc size : Φ 9 x 3 mm
Sample volume : up to 8000 μL
Elution volume : 500 – 8000 μL
Centrifuge : 1000 x g
Procedures
Product Lineup
주문 정보
< MonoSpin Short type (S type) >
| Description | Quantity | Cat.No. |
| MonoSpin C18 | 50 pcs | 501021700 5010-21700 |
| 100 pcs | 501021701 5010-21701 |
|
| MonoSpin C18FF | 50 pcs | 501021670 5010-21670 |
| 100 pcs | 501021671 5010-21671 |
|
| MonoSpin C18-AX | 50 pcs | 501021735 5010-21735 |
| 100 pcs | 501021736 5010-21736 |
|
| MonoSpin C18-CX | 50 pcs | 501021731 5010-21731 |
| 100 pcs | 501021732 5010-21732 |
|
| MonoSpin Phospholipid | 50 pcs | 501021698 5010-21698 |
| 100 pcs | 501021699 5010-21699 |
|
| MonoSpin TiO | 50 pcs | 501021705 5010-21705 |
| 100 pcs | 501021706 5010-21706 |
|
| MonoSpin NH2 | 50 pcs | 501021710 5010-21710 |
| 100 pcs | 501021711 5010-21711 |
|
| MonoSpin PBA | 50 pcs | 501021715 5010-21715 |
| 100 pcs | 501021716 5010-21716 |
|
| MonoSpin SAX | 50 pcs | 501021720 5010-21720 |
| 100 pcs | 501021721 5010-21721 |
|
| MonoSpin SCX | 50 pcs | 501021725 5010-21725 |
| 100 pcs | 501021726 5010-21726 |
|
| MonoSpin Amide | 50 pcs | 501021727 5010-21727 |
| 100 pcs | 501021728 5010-21728 |
|
| MonoSpin CBA | 50 pcs | 501021729 5010-21729 |
| 100 pcs | 501021730 5010-21730 |
|
| MonoSpin Ph | 50 pcs | 501021733 5010-21733 |
| 100 pcs | 501021734 5010-21734 |
|
| MonoSpin ME | 50 pcs | 501021737 5010-21737 |
| 100 pcs | 501021738 5010-21738 |
|
| MonoSpin Trypsin* (*Keep cool once delivered) |
50 pcs | 782011300 7820-11300 |
| 100 pcs | 782011301 7820-11301 |
|
| MonoSpin Trial Kit 1 (C18, TiO, SCX, SAX) | 4ｘ10 pcs | 501021740 5010-21740 |
| MonoSpin Trial Kit 1 (C18, TiO, SCX, SAX) | 4ｘ10 pcs | 501021741 5010-21741 |
| MonoSpin Trial Kit 3 (SCX, SAX, CBA, NH2) | 4ｘ10 pcs | 501021742 5010-21742 |
| Description | Quantity | Cat.No. |
| MonoSpin L C18 | 30 pcs | 751011320 7510-11320 |
| MonoSpin L SAX | 30 pcs | 751011321 7510-11321 |
| MonoSpin L SCX | 30 pcs | 751011322 7510-11322 |
| MonoSpin L NH2 | 30 pcs | 751011323 7510-11323 |
| MonoSpin L CBA | 30 pcs | 751011324 7510-11324 |
| MonoSpin L ME | 30 pcs | 751011325 7510-11325 |
| MonoSpin L Phospholipid | 30 pcs | 751011326 7510-11326 |
